REXROTH IndraDyn A Series User Manual

9-26 Application Notes Rexroth IndraDyn A
9.14 Attachment of Drive Elements
For all attachments of drive elements to the drive shaft, such as
• gearboxes
• couplings
• gear pinions
it is imperative that the following notes are observed.
Generally, overdetermined bearings are to be avoided by all means when
connecting drive elements. The tolerances inevitably present in such
cases will lead to additional forces acting on the motor bearing and
perhaps also to a distinctly reduced lifetime of the bearing or to a
progressive bending fracture or fatigue fracture of the motor shaft.
Attachment
of Drive Elements
effective
rotary radial force
permissible rotary
radial force?
(see Fig. 9-32)
Couplings
Pinions
Pulleys
- Helical Driving Pinion
- Bevel Gear Pinion
- directly geared
Bearing
"R"
Bearing
"H", "N", "V"
Only
restricted
allowed!
Observe the following notes
for the attachment of couplings!
Observe the following notes for
the attachment of Pinions!
Yes
No
Anbau von Antriebselementen_EN.EPS
Fig. 9-31: Attachment of Drive Elements
Note: If redundant attachment cannot be avoided, it is absolutely
necessary to consult with Bosch Rexroth.
Overdetermined Bearing
