6-10 Type Codes Rexroth IndraDyn A
6.5 Type Code for MAD180
1234 6789
1
05 1234 6789
2
05 1234 6789
3
05 1234 6789
4
05
Example:
Abbrev.
Column
MAD180C- 0050 -SA-C0 -KH0 - 35-N1
1
2
1. Product
1.1 MAD . . . . . . . = MAD
2. Size
2.1 180 . . . . . . . . . . . . . . = 180
3. Length
3.1 Lengths . . . . . . . . . . . . . . = C, D
4. Winding
4.1 MAD180C . . . = 0050, 0100, 0150, 0200
4.2 MAD180D . . . = 0050, 0100, 0150, 0200
5. Cooling
5.1 Axial blower, blowing . . . . . . . . . . . . . . . . . . = SA
6. Encoder
6.1 Singleturn absolute encoder with 512 increments = S0
6.2
Singleturn absolute encoder, EnDat2.1, with 2048
increments
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = S2
6.3 Multiturn absolute encoder with 512 increments = M0
6.4 Multiturn absolute encoder, EnDat2.1, with 2048
increments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = M2
6.5 Incremental encoder with 2048 increments . . . . . . = C0
6.6 without motor encoder . . . . . . . . . . . . . . . . . . . . . . = N0
7. Electrical connection
7.1 Terminal box connection, A-side . . . . . . . . . . . . . . . . . . . . = F
7.2 Terminal box connection, B-side . . . . . . . . . . . . . . . . . . . . = K
8. Shaft
with key
plain balanced with balanced with
shaft entire key half key
8.1
without shaft sealing ring
HQ L
8.2
with shaft sealing ring
GP K
9. Holding brake
9.1 without holding brake . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . = 0
9.2 electrically-released, 240 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . . = 2
9.3 electrically-clamped, 300 Nm . . . . . . . . . . . . . . . . . . . . . . . . . . . = 5
RNC-41171-800_NOR_E_D0_2004-09-153.EPS
Fig. 6-10: Type code for MAD180 (1/2)
