REXROTH IndraDyn A Series User Manual

Rexroth IndraDyn A Technical Data 4-49
Characteristic Curves of MAF100D
MAF100D-0050
0,0
50,0
100,0
150,0
200,0
250,0
0
500
1000 1500 2000 2500 3000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
1
2
3
4
5
6
7
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF100D_0050.FH10
Mit Regelgerät HMS01.1N-W0036 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0036 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-140: Characteristic curve of MAF100D-0050
MAF100D-0100
0,0
50,0
100,0
150,0
200,0
250,0
0
500
1000 1500 2000 2500 3000 3500 4000 4500 5000 5500 6000
Drehzahl/speed [min-1]
Drehmoment/Torque [Nm]
0
2
4
6
8
10
12
14
16
18
Leistung/power [kW]
M
max
M
nenn
P
max
P
nenn
KENNL-MAF100D_0100.FH10
Mit Regelgerät HMS01.1N-W0054 an Versorger HMV01.1E-W0120 an 3xAC400V (-5%)
With Drive Controller HMS01.1N-W0054 at HMV01.1E-W0120 with main connection 3xAC400V (-5%)
Fig. 4-141: Characteristic curve of MAF100D-0100
