4901 4
Black Display-Target [0 - 63 / 10 /step]
Displays the target value for the black-level adjustment executed during machine
initialization. Normally, the value is 10. Other values indicate that the adjustment has ended
unsuccessfully.
4901 5*
White Target [0 - 511 / 511 / 1/step]
Displays the target value for the white-level adjustment.
4901 6
White Result [0 - 511 / 0 / 1/step]
Displays the result of the white-level adjustment.
4901 8
White Display-Error [0 = Normal / 1 = Error]
Displays the return code of the white-level adjustment. When an error is detected, SC143
is generated.
4901 9
White Display-Overflow [0 = Normal / 1 = Error]
Displays a return code of the white-level adjustment. The code "1" (error) is returned if the
adjustment result is not in the range of the values in SP 4901 6.
4901 10
White Number of Attempt [0 - 20 / 0 / 1/step]
Displays how many times the white-level adjustment is retried. The value does not include
the first execution of the white adjustment. For example, if the value is "2", this indicates
that the white-level adjustment has been executed three times. The white-level adjustment
can be executed
20 times or less. Therefore, if the value is "20," this indicates that the white-
level adjustment has ended abnormally (as described, the value "20" does not include the
first execution). If the white-level adjustment is unsuccessful, the machine uses the result of
the latest, successful white-level adjustment.
4901 11
Auto Adjustment Setting [222 - 281 / 256 / 1/step]
Displays the parameter of the white-level adjustment. The value is based on the result of
SP 4901 12.
4901 12
Auto Adjustment-Result [0 - 600 / 0 / 1/step]
Displays the result of the white-level adjustment. Normally, the value is between 228 and
281 (including the both values). When the value is normal, it is stored as the value of SP
4901 11.
3. Appendix: SP Mode Tables
34
