Two-tray Paper Tray Unit Installation
Accessory Check
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Screw – M4x10 10
2 Unit Holder 2 x 2 pieces
3 Adjuster 1
4 Unit Holder 2
Installation Procedure
If the optional printer unit is installed:
Print out all data in the printer buffer.
Disconnect the network cable.
Unplug the machine power cord before starting the following procedure.
Two-tray Paper Tray Unit Installation
37
2
