Optional Equipment
ARDF
Original Size:
Standard sizes
• Single-sided mode: A3 to A5, 11" x 17" to
5
1
/
2
" x 8
1
/
2
"
• Double-sided mode: A3 to A5, 11" x 17" to
5
1
/
2
" x 8
1
/
2
"
Non-standard sizes (Single-sided mode only)
• Max. width 297 mm
• Min. width 105 mm
• Max. length 1260 mm
• Min. length 128 mm
Original Weight:
Single-sided mode: 40 – 128 g/m
2
,10 – 34 lb
Double-sided mode: 52 – 105 g/m
2
,14 – 28 lb
Table Capacity: 50 sheets (80 g/m
2
, 70 kg)
Original Standard Position: Center
Separation: FRR
Original Transport: Roller transport
Original Feed Order: From the top original
Reproduction Range: 50 to 200% (Sub scan direction only)
Power Source: 24 and 5 Vdc from the copier
Power Consumption: 50 W
Dimensions (W x D x H): 550 x 470 x 130 mm
Weight: 10 kg (22 lb)
Optional Equipment
13
