SP 8391 1 (Large Size Print Pages [A3/DLT, Larger])
SP 8411 1 (Prints Duplex)
1. Turn off the main switch.
2. Remove the card cover [B] (1 rivet).
3. Turn the face of the flash memory card [A] ("A" is printed on it) toward your left-hand side, and insert
it into the card slot.
4. Turn on the main switch.
5. Start the SP mode and select SP 5825 1.
6. The machine erases the current settings, then writes the new settings onto the NVRAM on the BICU
board. This takes about 1 second. If downloading fails, an error message appears. If an error message
appears, retry the download procedure.
7. Turn off the main switch.
8. Remove the memory card.
Test Pattern Print (SP 5902 1)
- Executing Test Pattern Printing -
1. Specify the pattern number and press the OK key.
2. Press the copy start key. The copy mode is activated
3. Specify copy settings and press the key.
4. To return to the SP mode, press the key.
- Test Patterns -
Test Patterns Using VCU
No. Pattern
0 (No print)
1 Vertical Lines (Single Dot)
2 Horizontal Lines (Single Dot)
3 Vertical Lines (Double Dot)
4 Horizontal Lines (Double Dot)
5 Grid Pattern (Single Dot)
6 Grid Pattern (Double Dot)
Using SP Modes
163
