Ricoh Aficio MP 1600L2 - Network Interface Board (D564); Component Check; Installing Expansion Component

Network Interface Board (D564)
• This option is used only for the model with the DDST Unit Type F (B865).
Component Check
No. Description Q’ty
1 Ferrite Core 1
2 Flexible Cable 1
3 Network Interface Board 1
Installing Expansion Component
• Unplug the machine power cord before starting the following procedure.
1. Unplug the DF cable [A] (if installed).
2. Installation
