2. Remove one screw [B] from the BICU.
3. Connect the controller box [D] to the BICU. Make sure that the BICU [E] is not damaged and that the
three openings [F][G][H] hold the controller box.
4. Fasten the screws ( x 7).
5. Re-attach the rear cover [A] ( x 6).
DDST Unit Type F (B865)
63
2
