Avoid areas exposed to sudden temperature changes:
1) Areas directly exposed to cool air from an air conditioner.
2) Areas directly exposed to heat from a heater.
Do not place the machine in areas where it can get exposed to corrosive gases.
Do not install the machine at any location over 2,000 m (6,560 ft.) above sea level.
Place the machine on a strong and level base. (Inclination on any side should be no more than 5
mm.)
Do not place the machine where it is subjected to strong vibrations.
Machine Level
Front to back: Within 5 mm (0.2") of level
Right to left: Within 5 mm (0.2") of level
Minimum Space Requirements
Place the copier near the power source, providing clearance as shown:
A (front): 750 mm (30")
B (left): 150 mm (6")
C (rear): 50 mm (2")
D (right): 250 mm (10")
2. Installation
20
