Ricoh Aficio MP 1600L2 - Copy Tray; Rear Lower Cover (Two-Tray Models Only)

Rear Lower Cover (Two-tray Models Only)
1. Rear cover (see above) or tray harness cover [A] (1 rivet).
2. Rear lower cover [B] ( x 2)
Copy Tray
1. Copy tray [A] ( x 2)
Exterior Covers & Operation Panel
77
4
