Platen Cover Installation
Accessory Check
Check that you have the accessories indicated below.
No. Description Q’ty
1 Stepped Screw 2
Installation Procedure
Unplug the machine power cord before starting the following procedure.
Install the platen cover ( x 2).
2. Installation
28
2
