1. Remove the strips of tape. Make sure that you have removed all the strips of tape and all the pieces
of cardboard.
• After removing the tape that secures the peripheral components and cardboard to the paper
tray, make sure that there is no tape and/or tape reside remaining on the tray.
2. Attach the adjuster [A] to the base plate as shown.
• This step is not necessary if a cabinet is installed.
2. Installation
38
