Bit Switches - 4
SM 111 D418
Fax Option
Type 9001
D418
4.6 BIT SWITCHES - 4
Do not adjust a bit switch or use a setting that is described as "Not used", as this
may cause the machine to malfunction or to operate in a manner that is not
accepted by local regulations. Such bits are for use only in other areas, such as
Japan.
Default settings for bit switches are not listed in this manual. Refer to the System
Parameter List printed by the machine.
4.6.1 G3 SWITCHES
G3 Switch 00 (SP No. 1-105-001)
No Function Comments
Monitor speaker during
communication (tx and rx)
Bit 1 Bit 0 Setting
0 0 Disabled
0 1 Up to Phase B
1 0 All the time
1 1 Not used
0
1
(0, 0): The monitor speaker is disabled all
through the communication.
(0, 1): The monitor speaker is on up to
phase B in the T.30 protocol.
(1, 0): Used for testing. The monitor
speaker is on all through the
communication. Make sure that you reset
these bits after testing.
2
Monitor speaker during memory
transmission
0: Disabled 1: Enabled
1: The monitor speaker is enabled during
memory transmission.
3-5 Not used Do not change the settings.
6
G3 mode selection for the direct
connection
0: Off
1: G3 communication through the direct line
is enabled.
To Next Page
