Replacement and
Adjustment
D454 12
SM
1.2.8
DYNAMIC ROLLER TRANSPORT MOTOR
1.
Rear upper cover (
p.4)
2.
Dynamic roller transport motor bracket [A](
x
1,
x
2)
3.
Dynamic roller transport motor (
x
2)
1.2.9 REGISTRATION
RO
LLER RELEASE MOTOR
1.
Rear upper cover (
p.4)
2.
Rear lower cover (
p.4)
1230
1232
