Test Pattern Printing
SM 5-13 D062/D063/D065/D066
System
Maintenance
No. Test Pattern
24 Auto Create Vertical Stripes
25 Auto Create Horizontal Stripes
26 Auto Create Grayscale Horizontal (20 mm)
27 Auto Create Grayscale Horizontal (40 mm)
28 Auto Create Grayscale Vertical (20 mm)
29 Auto Create Grayscale Vertical (40 mm)
30 Auto Create Argyle
5.3.3 IPU PRINTING TEST PATTERN: SP2902-004
This test pattern is generated in the application input processing circuit in the IPU. The
operation path is as follows:
Application input → Memory → Printer
This test pattern is primarily used for design purposes, but it can also be used to trace the
source of problems beyond the IPU (in the application input) which are causing poor print
quality.
1. Enter the SP mode and select SP2902-004.
2. Enter the number for the test pattern that you want to print and press
. (See the
table below.)
No. Pattern
0 Off
1 Vertical Grayscale 20
2 Horizontal Grayscale 40
3 Horizontal Grayscale 20
4 Horizontal Grayscale 25
5 Caterpillar
To Next Page
