REPLACEMENT AND ADJUSTMENT
B513/B531 24 SM
3.9 JOGGER UNIT B513 (OPTION)
3.9.1 JOGGER UNIT
1. Remove the jogger unit cover [A] ( x 2).
2. Remove the jogger unit [B] ( x 2, x 1).
B513I002.WMF
B513R003.WMF
[A]
[B]
