REPLACEMENT AND ADJUSTMENT
SM 19 B513/B531
Output
Jogger Unit/
Punch Unit
B513/B53131
3.7 SHIFT TRAY MOTOR
1. Remove the front door and rear cover ( 3.1).
2. Shift motor [A] ( x 2, x 3)
B478R531.WMF
[A]
