REPLACEMENT AND ADJUSTMENT
B513/B531 4 SM
Side Table and Upper Tray
1. Remove the side table [A] ( x 2). Slide to the right to remove it.
2. Click the release lever [B] and remove the upper tray [C].
B478R503.WMF
[A]
[B]
[C]
