EXTERNAL COVERS
SM 1 B473
Large
Capacity Tray
B473
1. REPLACEMENT AND ADJUSTMENT
1.1 EXTERNAL COVERS
[A]: Transport cover
[B]: Transport cover hinge ( x 1)
[C]: Rear cover ( x 4)
[D]: Top cover ( x 1)
[E]: Right cover ( x 2)
[F]: Front cover ( x 3)
B473R001.WMF
[A]
[B]
[C]
[D]
[E]
[F]
