Dedicated Transmission Parameters
D418 150 SM
Switch 01
No Function Function
0 1 0 Medium
0 1 1 High
1 1 1 Disabled
Quick/Speed Dial.
Also, try using the cable equalizer if
one or more of the following
symptoms occurs.
Communication error with error
codes such as 0-20, 0-23, etc.
Modem rate fallback occurs
frequently.
Do not use settings other
than listed on the left.
If the setting is “Disabled”,
the bit switch setting is used.
Switch 02
No Function Comments
Initial Tx modem rate (kbps)
Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0
Not
used
0 0 0 1 2.4
0 0 1 0 4.8
0 0 1 1 7.2
0 1 0 0 9.6
0 1 0 1 12.0
0
to
3
0 1 1 0 14.4
If training with a particular remote terminal
always takes too long, the initial modem
rate may be too high. Reduce the initial Tx
modem rate using these bits.
For the settings 14.4 or kbps slower,
Switch 04 bit 4 must be changed to 0.
Other settings: Not used
If the setting is “Disabled”, the bit switch
setting is used.
