Electrical Component
s: 2nd Stopper
SM 29
D454
Multi-Folding
Unit FD5000
D454
10.
Open the jam removal door [A], and then remove the 2nd stopper unit [B].
1.4.2 2ND
STOPPER
MOTOR
1.
2nd stopper unit (
p.27)
2.
2nd stopper motor [A] (
x
1,
x
1,
x
2)
1.4.3
2ND STOPPER HP SENSOR
1.
2nd stopper unit (
p.27)
1247
1249
