Replacement and
Adjustment
D454 36
SM
2.
Rear lower cover (
p.4)
3.
Registration roller HP sensor bracket [A] (
x
1,
x
1)
4.
Registration roller HP sensor [A] (hooks)
1.5.7
FOLD PLATE HP SENSOR
1.
Rear upper cover (
p.4)
2.
Rear lower cover (
p.4)
1254
1256
