Paper Feed
SM 4-89
D062/D063/D065/D066
Repla
cement
and
Adjustment
6.
Remove the tray cover [E] (
x
3).
7.
Remove the DC motor cover [F] (
x
5).
8.
Remove the rear side fence [G] (
x 4) and re-position the rear cover [H] (
x
2).
9.
Re-position the si
de fences [I] [J] (
x
4).
A4: Outer slot position
L
T
: Inner slot position
275
277
