Service Call Conditions
SM Appendix 3-37 D062/D063/D065/D066
Appendix:
Service Call
Conditions
ARDF feed motor disconnected, defective
Bottom plate HP sensor disconnected, defective
ARDF main board defective
Finisher transport motor error
720 D
The encoder pulse of the finisher
transport motor does not change
state (high/low) within 600 ms
and does not change after 2
retries.
Finisher transport motor defective
Transport motor harness
disconnected, or defective
Finisher main board defective
Finisher jogger motor error
721 B
The finisher jogger HP
sensor remains de-activated
for more 1,000 pulses when
returning to home position.
The finisher jogger HP
sensor remains activated for
more than 1,000 pulses
when moving away from
home position.
Jogger HP sensor defective
Jogger mechanism overload
Jogger motor defective (not rotating)
Finisher main board defective
Harness disconnected or defective
Finisher staple hammer motor error (D460)
724 B
The staple hammer motor did
not return to the home position
within the prescribed time (340
ms).
Staple hammer HP sensor loose,
broken, defective
Electrical overload on the stapler
drive PCB elect
Staple hammer motor defective
Finisher main board defective
