Service Call Conditions
SM Appendix 3-39 D062/D063/D065/D066
Appendix:
Service Call
Conditions
Finisher corner stapler motor error
740 B
The stapler motor does not
switch off within the prescribed
time after operating. The 1st
detection failure issues a jam
error, and the 2nd failure issues
this SC code.
 Staple jam
 Number of sheets in the stack
exceeds the limit for stapling
 Stapler motor disconnected,
defective
Finisher corner stapler rotation motor error
741 B
The stapler does not return to its
home position within the
specified time after stapling. The
1st detection failure issues a jam
error, and the 2nd failure issues
this SC code.
 Stapler rotation motor disconnected,
defective
 Stapler rotation motor overloaded
due to obstruction
 Stapler rotation HP sensor
disconnected, defective
Finisher stapler movement motor error
742 B
The stapler HP sensor is not
activated within the specified
time after the stapler motor
turned on. The 1st detection
failure issues a jam error, and the
2nd failure issues this SC code.
 Stapler movement motor
disconnected, defective
 Stapler movement motor overloaded
due to obstruction
 Stapler HP sensor disconnected,
defective
Booklet stapler motor error 1
743 B
The front stapler unit
saddle-stitch motor does not start
operation within the specified
time. The 1st detection failure
issues a jam error, and the 2nd
failure issues this SC code.
 Front motor disconnected, defective
 Front motor overloaded due to
obstruction
