Service Call Conditions
SM Appendix 3-83 D062/D063/D065/D066
Appendix:
Service Call
Conditions
No. Location Position Code
155 Pre-Stack R4 to R7
156 Feed Out R4 to R7
158 Upper Trans Motor R1 to R3
159 Shift Tray Motor R1 to R3
160 Positioning Roller Motor R4 to R7
161 Jogger Fence Motor R4 to R7
162 Stack Plate Motor (Center) R4 to R7
163 Stack Plate Motor (Front) R4 to R7
164 Stack Plate Motor (Rear) R4 to R7
165 Shift Motor R1 to R3
166 Drag Drive Motor R1 to R3
167 Shift Tray Jogger Motor R1 to R3
168 Shift Tray Jogger Retraction Motor R1 to R3
169 Exit Guide Motor R4 to R7
170 Staple Hammer Motor -
171 Stapler Movement Motor R4 to R7
172 Stapler Rotation Motor R4 to R7
173 Stack Feed-Out Belt Motor R4 to R7
174 Punch Motor R1 to R3
175 Top Fence Motor R4 to R7
176 Bottom Fence Motor R4 to R7
197 Main Machine Set. Incorrect
R1 to R3
/ R4 to R7
To Next Page
