Service Program Mode Tables
D062/D063/D065/D066 4-54 SM Appendix
007 Brightness: 1-255
Set higher for darker, set lower for lighter.
[1 to 255/128/1]
008 Contrast: 1-255
Set higher for more contrast, set lower for less contrast.
[1 to 255/128/1]
009 Independent Dot Erase: 0-7 (0:Low, 7 High)
This SP sets the level for removing dots when a color original is scanned with a
scanner software application. The higher the setting, the greater the effect
applied for removing background dots.
[0 to 7/0/1]
010 Texture Erase: 0-2
[0 to 2/0/1]
4600* Display the ID of ASIC
001
Displays the VSBCNT ID code confirmed by reading the SBU after the SBU
adjusts automatically at power on.
[0 to FFh/1]
002
Displays the DAGL_L ID code confirmed by reading the SBU after the SBU
adjusts automatically at power on.
[0 to FFh/1]
003
Displays the DAGL_F ID code confirmed by reading the SBU after the SBU
adjusts automatically at power on.
[0 to FFh/1]
4609*
Gray Balance Adj Value: R DFU
001 Displays the reference voltage for Red adjusted by gray balance adjustment.
4610*
Gray Balance Adj Value: G DFU
