Service Program Mode Tables
D062/D063/D065/D066 4-72 SM Appendix
4792 White Level Peak Data G
FC
001
Displays the current red data of white level peak data for Green in the full color
mode.
[0 to 255 / - / 1 digit]
BK
002
Displays the current red data of white level peak data for Green in the B/W
mode.
[0 to 255 / - / 1 digit]
4793 Black Level Data R
4794 Black Level Data G
4795 Black Level Data B
001
to
024
Displays the current red data of black level for each color signal and chip.
[0 to 255 / - / 1 digit]
4796*
Chip Color Stripe Correct DFU
4797*
Digital AE: Back DFU
001
Low Limit Value [0 to 1023/ 392 / 1 digit]
002
Background level [0 to 1023/ 972 / 1 digit]
4798
LED Lighting Duty: Back DFU
001 FC
002 BK
To Next Page
