Service Program Mode Tables
D062/D063/D065/D066 4-76 SM Appendix
002 Independent Dot Erase: Copy/Original
0: Softest
1: Soft Mode
4: Normal (Default)
6: Sharp Mode
7: Sharpest
4905
Gradation Processing Selection DFU
4907 SBU Test Pattern
001 Select Test Pattern
0: Normal
1: Fixed Value
2: Main Scan Grayscale
3: Sub Scan Grayscale
4: Checked Pattern
002 Set Output Level
Output level in case of setting
SP4-907-1 to 1.
[0 to 1023/512/1]
Manual Gamma Adjustment DFU
4918
-009
IPU Image Pass Selection RGB Frame Memory DFU
4991
[0 to 11/2/1]
High Light Correction DFU
4993
[0 to 9/4/1]
001 Sensitivity Selection
002 Range Selection
