Main Machine
SM 2-17
D062/D063/D065/D066
Inst
allation
6.
Remove the tray cover [A] (
x
3).
7.
Remove the motor cover [B] (
x
5).
8.
Re-position the side fences [A] (
x 8).
The outer slot pos
ition is used when loading
A4 size paper
.
9.
Re-install the motor cover and the tray cover
.
