Using the Standard TCP/IP port
1. Quit all applications. (Do not close this manual.)
2. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] dialog box appears, click [Run AUTORUN.EXE].
3. Select an interface language, and then click [OK].
For details about the languages supported in the printer drivers, see p.6 "Supported languages".
4. Click [PCL Printer Drivers] or [PostScript 3 Printer Driver].
5. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next].
If installing the PostScript 3 printer driver, proceed to step 7.
6. Select a printer driver you want to use, and then click [Next].
7. Select the check box of the manufacturer and machine model you want to use.
8. Double-click the machine name to display the printer settings.
9. Click [Port :], and then click [Add] in the [Change settings for 'Port'] box.
10. Click [Standard TCP/IP Port], and then click [OK].
If [Standard TCP/IP Port] does not appear, see Windows Help, and then configure the settings.
11. Click [Next].
12. Enter the machine name or IP address, and then click [Next].
When the device type selection appears, select "RICOH Network Printer C model".
13. Click [Finish].
14. Check that the port of the selected printer is displayed in [Port :].
15. Configure the user code, default printer, and shared printer as necessary.
16. Click [Continue].
The installation starts.
17. Click [Finish].
Select one of the options to restart the computer either now or later, and then click [Finish].
Using the IPP port
• To print via IPP-SSL, use the SmartDeviceMonitor for Client port.
Installing the Printer Driver for a Network Connection
15
