Encryption key manual settings items
Setting Description Setting value
Address Type
Specify the address
type for which IPsec
transmission is used.
• Inactive
• IPv4
•
IPv6
• IPv4/IPv6 (Default Settings only)
Local Address
Specify the machine's
address. If you are
using multiple IPv6
addresses, you can
also specify an
address range.
The machine's IPv4 or IPv6 address.
If you are not setting an address range, enter
32 after an IPv4 address, or enter 128 after an
IPv6 address.
Remote Address
Specify the address
of the IPsec
transmission partner.
You can also specify
an address range.
The IPsec transmission partner's IPv4 or IPv6
address.
If you are not setting an address range, enter
32 after an IPv4 address, or enter 128 after an
IPv6 address.
Encapsulation Mode
Select the
encapsulation mode.
• Transport
• Tunnel
(Tunnel beginning address - Tunnel ending
address)
If you select "Tunnel", set the "Tunnel End Point",
the beginning and ending IP addresses. In
"Tunnel End Point", set the same address for the
beginning point as you set in "Local Address".
SPI (Output)
Specify the same
value as your
transmission partner's
SPI input value.
Any number between 256 and 4095
SPI (Input)
Specify the same
value as your
transmission partner's
SPI output value.
Any number between 256 and 4095
Configuring IPsec
153
