9. Bypass tray
Use to copy or print on OHP transparencies and label paper (adhesive labels).
10. Extender
Pull this extender out when loading A4 , 8
1
/
2
× 11 or larger size paper in the bypass tray.
11. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
12.
Lower right cover
Open this cover when a paper jam occurs.
13. Right cover
Open this cover to remove jammed paper fed from the paper tray.
Front and left view
1. Internal tray guide
Open out and raise the end fence to support large paper.
2. Extenders
Raise these extenders to support large paper.
3.
Internal tray
Copied/printed paper and fax messages are delivered here.
Guide to Names and Functions of Components
31
