7. Select the printer model you want to use.
The printer name can be changed in the [Change settings for 'Printer Name'] box.
8. Double-click the printer name to display the printer settings.
The details shown in [Comment:], [Driver:], and [Port:] vary depending on the operating system, printer
model, and port.
9. Click [Port:], and then click [Add].
10. Click [SmartDeviceMonitor], and then click [OK].
11. Click [IPP].
12. In the [Printer URL] box, enter "http://printer's address/printer" as the printer's address.
If the server authentification is issued, to enable SSL( a protocol for encrypted communication), enter
"https://printer's address/printer" (Internet Explorer 5.01, or a higher version must be installed).
(example IPv4 address: 192.168.15.16)
http://192.168.15.16/printer
https://192.168.15.16/printer
You can enter "http: //printer's address/ipp" as the printer's address.
13. Enter a name for identifying the printer in [IPP Port Name]. Use a name different from the
one of any existing port.
If a name is not specified here, the address entered in the [Printer URL] box becomes the IPP port
name.
14. Click [Detailed Settings] to make necessary settings.
For information about the settings, see SmartDeviceMonitor for Client Help.
15. Click [OK].
16. Check that the port of the selected printer is displayed in [Port:].
17. Set a User Code, if necessary.
Up to 8 numeric characters can be entered. No alphabetic characters or symbols can be entered.
18. Select the [Default Printer] check box to configure the printer as default.
19. Click [Continue].
Installation starts.
20. After the installation is completed, select one of the options to restart the computer either
now or later, and then click [Finish].
Restart the computer to complete installation.
• Auto Run may not work with certain operating system settings. If this happens, launch "Setup.exe" on
the CD-ROM root directory.
1. Preparing for Printing
26
