Paper Feed Sensor, Paper End Sensor, Limit Sensor, Transport Sensor

SM 15 D696

LCIT RT3030

(D696)

5. Paper end sensor [A] (

×1)

6. Limit sensor [A] (

×1)

7. Transport sensor [A] (

×1)
