Service Call 101-195
D146/D147/D148/D149/D150 5-20 SM
SC No. Level Error Name/Error Condition/Major Cause/Solution
SC188-00 D CIS white level error
§ The shading data peak value read out from the CIS is
abnormal.
§ The shading data peak value is not within the specified
range from the target value.
Details:
§ Occurs when abnormality is detected in the process of CIS
shading data peak detection.
§ The first and second consecutive occurrences constitute
initial jams. The third occurrence constitutes an SC.
CIS defective
1. Reconnect the power/signal harness.
2. Replace the following parts:
§ Replace the CIS and CIPB.
§ Replace the CIS background white roller.
§ Replace the power/signal harness.
