Ricoh D148 - Page 679

Jam Detection
SM 5-205 D146/D147/D148/D149/D150
Troubleshooting
Cause code Cause of jam Display code
53 Paper did not clear vertical transport
sensor 3
Y
1 There is paper in vertical transport sensor
3
Y
7 Paper not fed from LCT U1
15 Paper did not reach LCT transport sensor U
58 Paper did not clear LCT transport sensor U
1 There is paper in LCT transport sensor U
Bridge Unit BU3070
Cause code Cause of jam Display code
21 Paper did not reach relay output sensor D
22 Paper did not reach relay transport sensor D
61 Paper did not clear relay output sensor D
62 Paper did not clear relay transport sensor D
Internal Finisher SR3130
Cause code Cause of jam Display code
100 Paper did not reach inlet sensor R1-R2
101 Paper held up at inlet sensor R1-R2
102 Paper did not reach transport sensor R1-R2
103 Paper held at transport sensor R1-R2
104 Paper output unit R1-R2
105 Front jogger motor R1-R2
106 Rear jogger motor R1-R2
