• The paper feed belt unit must be pulled out horizontally relative to the paper tray, to ensure that the
paper feed belt is not damaged by getting caught in the side fences or other parts.
• To prevent damaging the paper feed belt when you return the paper feed belt unit to its original
position, align the right and left guides [A] with the rail [B] on the paper tray side and raise them
slightly before replacing the unit.
1. Replacement and Adjustment
18
