9. Troubleshooting Guide RICOH Ri 2000 User Manual
226
Take the filled cleaning liquid with the head protection cover under the carriage to
prevent spillage.
If cleaning solution spills when the head protection cover is pushed up, wipe it off.
After attaching the head protection cover, observe it from the front and check if the head
protection cover is not tilted.
If it is tilted, a gap may be visible between the carriage and the cap inside the head protection
cover, as shown in the NG image below. In this case, perform the installation again.
Check if the claw on the side that is not visible in the shadow of the carriage when the head
protection cover is installed is properly engaged.
To Next Page
