Ricoh SR4110 User Manual

1.Detailed Descriptions
7
No. Description No. Description
1 Leading Edge Stopper Motor 14 Paper Hold Front Motor
2 Positioning Roller Motor 15 Used Staple Disposing Solenoid
3 Drag-in Motor 16 Stapler Rotation Motor
4 Drag-in HP Sensor 17 Stapler Movement HP Sensor
5 Stapler Front/rear Motor 18 Stapler Rotation Sensor
6 Paper Hold Center Motor 19 Feed Out Belt HP Sensor
7 Paper Hold HP Sensor 20 Staple Tray Paper Sensor
8 Paper Hold Rear HP Sensor 21 Bottom Fence HP Sensor
9 Paper Hold Rear Motor 22 Bottom Fence Motor
10 Paper Hold Front HP Sensor 23 Jogger HP Sensor
11 Staple Hammer HP Sensor 24 Jogger Motor
12 Staple Cartridge Set Sensor 25 Feed Out Belt Motor
13 Staple Motor 26 Leading Edge Stopper HP Sensor

Ricoh SR4110 Specifications

General

Brand	Ricoh
Model	SR4110
Category	Finishers
Language	English
