No. Name Description

4 USB HOST

Connect the instrument (as "host" device)

to external USB device (such as USB

storage device).

5 AC selector

Select the specification of the input

voltage: 100, 120, 220, or 230 (please

refer to

Connecting to Power

6 AC power inlet socket AC inlet power connector

7 Fuse

The fuse rating is related to the

instrument model and actual input

voltage (please refer to

Table 4.4 Fuse

Rating

AC input power

requirement

The table describes the relationship

between the frequency and voltage of the

input power, and fuse rating.

9 Ground terminal -

10 Fan ventilation hole -

Note[1]: Digital I/O is optional for DP932U and not available for DP932E

4.5 User Interface

Tap > Display to assess the interface as shown in the figure below. This section

introduces the meter-view display of the power supply.

Quick Start

DP900 User Guide

Table of Contents3
Safety Requirement9
General Safety Summary9
Safety Notices and Symbols11
Measurement Category11
Ventilation Requirement12
Working Environment12
Care and Cleaning14
Environmental Considerations14
Product Overview16
Document Overview18
Quick Start20
General Inspection20
Appearance and Dimensions21
Front Panel21
Figure 4.1 Front View21
Figure 4.2 Side View21
Figure 4.3 DP900 Front Panel22
Figure 4.4 DP900 Output Terminals24
Rear Panel25
Figure 4.5 DP900 Rear Panel25
Table 4.1 DP900 Rear Panel Description25
User Interface26
Figure 4.6 User Interface27
Table 4.2 User Interface Description27
Connecting to Power28
Table 4.3 AC Input Power Specifications (Including AC Selector Setting)28
Power-On Inspection29
Connecting the Outputs30
Replacing the Fuse30
Using the Built-In Help System31
Table 4.4 Fuse Rating31
Figure 4.7 Help Interface32
Using the Protection Function33
Figure 5.1 CH1 Output Settings Interface33
Constant Voltage Output35
Constant Current Output38
Series/Parallel Connections39
Series Connections39
Figure 8.1 Series Output Interface40
Parallel Connections41
Figure 8.2 External Series Circuit41
Figure 8.3 Parallel Output Interface42
Figure 8.4 External Parallel Circuit43
Arb Function44
Figure 9.1 Arb Main Interface44
Setting Arb Properties45
Figure 9.2 Arb Settings Interface45
Arb Editor47
Figure 9.3 Arb Editor Interface47
Inserting a Single Point48
Editing Waveform Templates48
Figure 9.4 Template Editing Menu48
Table 9.1 Arb Parameters (Template)52
Delete54
Import and Export54
Enabling the Arb Output55
Figure 9.5 Arb Output Interface55
Analyzer56
Common Analysis56
Figure 10.1 Analyzer Main Interface56
Selecting Analysis Object57
Figure 10.2 Common Analysis Setting Interface57
Figure 10.3 Analysis Object Setting Menu57
Selecting Statistical Method58
Pulse Current Analysis59
Figure 10.4 Pulse Current Analysis Setting Interface59
Data Logging60
Figure 10.5 Pulse Current Analysis Interface60
Figure 10.6 Log Setting Interface60
Print Screen61
Label Control61
Trigger62
Figure 11.1 Digital Port Connections62
Trigger Input63
Figure 11.2 Trigger Setting Interface63
Figure 11.3 Trigger Input Setting Interface64
Trigger Output65
Figure 11.4 Trigger Output Setting Interface65
Store and Recall67
Figure 12.1 Disk Interface67
Select68
Save68
Read69
Delete69
Copy and Paste70
Utility71
System Settings71
Instrument Settings71
Figure 13.1 Utility Interface71
Figure 13.2 Instrument Settings Interface72
Table 13.1 Factory Default Values72
Display Options74
Output Settings75
Figure 13.3 Display Options Interface75
Track Mode76
Safe Mode76
Figure 13.4 Output Settings Interface76
Output Connection77
Output off Mode77
Interface Settings78
LXI Status78
Figure 13.5 Interface Settings78
Figure 13.6 LXI Status Interface79
LXI Setting80
Figure 13.7 LXI Settings Menu80
USB Configuration82
Option Settings83
Figure 13.8 USB Configuration Interface83
Figure 13.9 Option Settings Interface84
Locking/Unlocking the Front Panel86
Remote Control88
Remote Control Via USB88
Remote Control Via LAN89
Troubleshooting91
Specifications93
Appendix99
Appendix A: Accessories and Options99
Appendix B: Warranty100
