Chapter 5 Trigger RIGOL

MSO4000/DS4000 User’s Guide 5-47

You can make the following settings:

a. Press ID Setup to select “Random ID” or “Specific ID”.

When “Random ID” is selected, the ID data will not be used as the

trigger condition. When “Specific ID” is selected, press ID

Format to select “Standard” or “Expand”; press ID Data and

turn the multi-function knob

or the inner knob of the

navigation knob to adjust the ID data at a relatively smaller step

or turn the outer knob of the navigation knob to adjust the ID data

at a relatively larger step. The range of the ID data is from 0 to

2047 (standard ID format) or from 0 to 536870911 (expanded ID

format).

Note: The larger the rotation amplitude of the outer knob of the

navigation knob is, the faster the variation of the value will be.

When you need to adjust the ID data within a relatively larger

range, this function can help you quickly finish the setting.

b. Press Byte Length and turn the multi-function knob to select

the desired byte length. The range is from 1 to 8.

c. Press CurrentBit and turn the multi-function knob to select

the data bit to be operated and the range is from 0 to (the current

“Byte Length”×8-1).

d. Press Data to set the data pattern of the current data bit to H, L or

X. You can also switch the data pattern of the current data bit by

pressing the multi-function knob

continuously after you set

the CurrentBit.

e. Press AllBits to set the patterns of all the bits to the pattern of the

current data bit (namely the pattern in Data).

 When “Remote” is selected, you can make the ID settings by referring

to step a above.

2) Frame Error:

When the trigger condition is set to “Frame Error”, press Error Type and

turn the multi-function knob

to select the desired error type. You can
