RIGOL Chapter 17 Specifications
17-4 MSO4000/DS4000 User’s Guide
Vertical
Bandwidth (-3 dB)
(50 Ω)
MSO405X/DS405X: DC to 500 MHz
MSO403X/DS403X: DC to 350 MHz
MSO402X/DS402X: DC to 200 MHz
MSO401X/DS401X: DC to 100 MHz
Single Bandwidth
(50 Ω)
MSO405X/DS405X: DC to 500 MHz
MSO403X/DS403X: DC to 350 MHz
MSO402X/DS402X: DC to 200 MHz
MSO401X/DS401X: DC to 100 MHz
Vertical Resolution Analog channel: 8 bits, two channels sample at the same
time
Digital channel: 1 bit
Vertical Scale 1 MΩ input impedance: 1 mV/div to 5 V/div
50 Ω input impedance: 1 mV/div to 1 V/div
Offset Range 1 MΩ input impedance:
1 mV/div to 225 mV/div: ±2 V
230 mV/div to 5 V/div: ±40 V
50 Ω input impedance:
1 mV/div to 124 mV/div: ±1.2 V
126 mV/div to 1 V/div: ±12 V
Dynamic Range ±5 div
Bandwidth Limit
[1]
MSO405X/DS405X: 20 MHz/100 MHz/200 MHz
MSO403X/ DS403X: 20 MHz/100 MHz/200 MHz
MSO402X/DS402X: 20 MHz/100 MHz
MSO401X/DS401X: 20 MHz
Low Frequency
Response
(AC Coupling,
-3 dB)
≤5 Hz (on BNC)
Calculated Rise
Time
[1]
MSO405X/DS405X: 700 ps
MSO403X/DS403X: 1 ns
MSO402X/DS402X: 1.8 ns
MSO401X/DS401X: 3.5 ns
DC Gain Accuracy ±2% full scale
DC Offset Accuracy 200 mV/div to 5 V/div: ±0.1 div ± 2 mV ± 0.5% offset
