Chapter 1 Quick Start RIGOL
MSO4000/DS4000 User’s Guide 1-33
11. CH1 Status Label
 Display the on/off status of CH1. When it is on, the status label is
highlighted.
 Display the vertical scale of CH1 (namely the voltage value per grid of the
CH1 waveform in the vertical direction). You can use VIRTICAL
SCALE
under CH1 to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the channel coupling (refer to “To
Specify the Channel Coupling”) is AC;
is displayed when the
bandwidth limit (refer to “To Specify the Bandwidth Limit”) is enabled;
is displayed when the input impedance (refer to “To Specify the Input
Impedance”) is 50 Ω.
12. CH2 Status Label
 Display the on/off status of CH2. When it is on, the status label is
highlighted.
 Display the vertical scale of CH2 (namely the voltage value per grid of the
CH2 waveform in the vertical direction). You can use VIRTICAL
SCALE
under CH2 to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the channel coupling (refer to “To
Specify the Channel Coupling”) is AC;
is displayed when the
bandwidth limit (refer to “To Specify the Bandwidth Limit”) is enabled;
is displayed when the input impedance (refer to “To Specify the Input
Impedance”) is 50 Ω.
13. CH3 Status Label
 Display the on/off status of CH3. When it is on, the status label is
highlighted.
 Display the vertical scale of CH3 (namely the voltage value per grid of the
CH3 waveform in the vertical direction). You can use VIRTICAL
SCALE
under CH3 to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the channel coupling (refer to “To
Specify the Channel Coupling”) is AC;
is displayed when the
bandwidth limit (refer to “To Specify the Bandwidth Limit”) is enabled;
is displayed when the input impedance (refer to “To Specify the Input
Impedance”) is 50 Ω.
