Rinstrum C530 User Manual

Register Name Type Write Read Read Response Description
2001 ADDRESS UINT16 ADR<value>; ADR?; <value> Device network address
2002 PRINT MODE UINT16 PRS,<value>; PRS?; ,<value> Printer mode
2003 AUTO OUT FMT UINT16 PRS,,<value>; PRS?; ,,<value> Automatic output format
2004 PRINT COLUMNS UINT16 PRS,,,<value>; PRS?; ,,,<value> Printer ticket columns
2005 PRINT ROWS UINT16 PRS,,,,<value>; PRS?; ,,,,<value> Printer ticket rows
2006 AUTO OUT SOURCE UINT16 PRS,,,,,<value>; PRS?; ,,,,,<value> Automatic output source
2101 SER0 M1A TYPE UINT16 BDX0,<value>; BDX?0; 0,<value> Serial module 1A port type
2102 SER0 M1A BAUD UINT16 BDX0,,<value>; BDX?0; 0,,<value> Serial module 1A port baud
2103 SER0 M1A PARITYBITS UINT16 BDX0,,,<value>; BDX?0; 0,,,<value> Serial module 1A port parity bits
2104 SER0 M1A DATABITS UINT16 BDX0,,,,<value>; BDX?0; 0,,,,<value> Serial module 1A port data bits
2105 SER0 M1A STOPBITS UINT16 BDX0,,,,,<value>; BDX?0; 0,,,,,<value> Serial module 1A port stop bits
2106 SER0 M1A TERMINATIONS UINT16 BDX0,,,,,,<value>; BDX?0; 0,,,,,,<value> Serial module 1A port use
terminations
2107 SER0 M1A CTS UINT16 BDX0,,,,,,,<value>; BDX?0; 0,,,,,,,<value> Serial module 1A port use CTS
2111 SER1 M1B TYPE UINT16 BDX1,<value>; BDX?1; 1,<value> Serial module 1B port type
2116 SER1 M1B TERMINATIONS UINT16 BDX1,,,,,,<value>; BDX?1; 1,,,,,,<value> Serial module 1B port use
terminations
2117 SER1 M1B CTS UINT16 BDX1,,,,,,,<value>; BDX?1; 1,,,,,,,<value> Serial module 1B port use CTS
2121 SER2 M2A TYPE UINT16 BDX2,<value>; BDX?2; 2,<value> Serial module 2A port type
2122 SER2 M2A BAUD UINT16 BDX2,,<value>; BDX?2; 2,,<value> Serial module 2A port baud
2123 SER2 M2A PARITYBITS UINT16 BDX2,,,<value>; BDX?2; 2,,,<value> Serial module 2A port parity bits
2124 SER2 M2A DATABITS UINT16 BDX2,,,,<value>; BDX?2; 2,,,,<value> Serial module 2A port data bits
2125 SER2 M2A STOPBITS UINT16 BDX2,,,,,<value>; BDX?2; 2,,,,,<value> Serial module 2A port stop bits
2126 SER2 M2A TERMINATIONS UINT16 BDX2,,,,,,<value>; BDX?2; 2,,,,,,<value> Serial module 2A port use
terminations
2127 SER2 M2A CTS UINT16 BDX2,,,,,,,<value>; BDX?2; 2,,,,,,,<value> Serial module 2A port use CTS
2131 SER3 M2B TYPE UINT16 BDX3,<value>; BDX?3; 3,<value> Serial module 2B port type
2136 SER3 M2B TERMINATIONS UINT16 BDX3,,,,,,<value>; BDX?3; 3,,,,,,<value> Serial module 2B port use
terminations
2137 SER3 M2B CTS UINT16 BDX3,,,,,,,<value>; BDX?3; 3,,,,,,,<value> Serial module 2B port use CTS
2141 SER4 TCPPORT UINT16 BDX4,,,,,,,,,<value>; BDX?4; 4,,,,,,,,,<value> Serial network TCP listen port
2151 SER5 TCPPORT UINT16 BDX5,,,,,,,,,<value>; BDX?5; 5,,,,,,,,,<value> Serial auto output TCP listen
port
2161 SER6 USBSLAVE TYPE UINT16 BDX6,<value>; BDX?6; 6,<value> Serial USB slave port type
2171 SER7 USBHOST TYPE UINT16 BDX7,<value>; BDX?7; 7,<value> Serial USB host port type
2172 SER7 USBHOST BAUD UINT16 BDX7,,<value>; BDX?7; 7,,<value> Serial USB host port baud
2173 SER7 USBHOST PARITYBITS UINT16 BDX7,,,<value>; BDX?7; 7,,,<value> Serial USB host port parity bits
2174 SER7 USBHOST DATABITS UINT16 BDX7,,,,<value>; BDX?7; 7,,,,<value> Serial USB host port data bits
2175 SER7 USBHOST STOPBITS UINT16 BDX7,,,,,<value>; BDX?7; 7,,,,,<value> Serial USB host port stop bits
2177 SER7 USBHOST CTS UINT16 BDX7,,,,,,,<value>; BDX?7; 7,,,,,,,<value> Serial USB host port use CTS
2191 MODBUS ENDIAN UINT16 MBS<value>; MBS?; <value> Modbus endian
2192 MODBUS TCP PORT UINT16 MBS,<value>; MBS?; ,<value> Modbus TCP port
2201 AUTO OUT FMT CUSTOM STR(246) AFT<value>; AFT?; <value> Auto output format
2401 DHCP ENABLE UINT16 ETH<value>; ETH?; <value> Ethernet DHCP enable
2402 IP ADDR STR(15) ETH,<value>; ETH?; ,<value> Ethernet IP address
2410 NETMASK STR(15) ETH,,<value>; ETH?; ,,<value> Ethernet network mask
2418 DEFGW STR(15) ETH,,,<value>; ETH?; ,,,<value> Ethernet default gateway
2426 DNS STR(15) ETH,,,,<value>; ETH?; ,,,,<value> Ethernet DNS server
2434 MAC ADDR STR(17) ETH?; ,,,,,,<value> Ethernet MAC address
2443 HOSTNAME STR(64) ETH,,,,,,,<value>; ETH?; ,,,,,,,<value> Ethernet hostname
2501 PRINT FORMAT STR(246) PFT<value>; PFT?; <value> Printer format
2701 PRINT HDR1 STR(30) PST1,<value>; PST?1; <value> Printer header line 1
2716 PRINT HDR2 STR(30) PST2,<value>; PST?2; <value> Printer header line 2
2731 PRINT HDR3 STR(30) PST3,<value>; PST?3; <value> Printer header line 3
2746 PRINT HDR4 STR(30) PST4,<value>; PST?4; <value> Printer header line 4
2761 PRINT HDR5 STR(30) PST5,<value>; PST?5; <value> Printer header line 5
2776 PRINT HDR6 STR(30) PST6,<value>; PST?6; <value> Printer header line 6
2801 TEXT STR1 STR(40) TXT1,<value>; TXT?1; 1,<value> Text string 1 (thumbwheel)
2821 TEXT STR2 STR(40) TXT2,<value>; TXT?2; 2,<value> Text string 2 (thumbwheel)
2841 TEXT STR3 STR(40) TXT3,<value>; TXT?3; 3,<value> Text string 3 (thumbwheel)
2861 TEXT STR4 STR(40) TXT4,<value>; TXT?4; 4,<value> Text string 4 (thumbwheel)
2881 TEXT STR5 STR(40) TXT5,<value>; TXT?5; 5,<value> Text string 5 (thumbwheel)
2901 TEXT STR6 STR(40) TXT6,<value>; TXT?6; 6,<value> Text string 6 (thumbwheel)
2921 TEXT STR7 STR(40) TXT7,<value>; TXT?7; 7,<value> Text string 7 (thumbwheel)
2941 TEXT STR8 STR(40) TXT8,<value>; TXT?8; 8,<value> Text string 8 (thumbwheel)
2961 TEXT STR9 STR(40) TXT9,<value>; TXT?9; 9,<value> Text string 9 (thumbwheel)
3001 ENABLE UINT16 BUZ<value>; BUZ?; <value> Buzzer enable
97 C500-600-2.0.3
