Rinstrum C530 User Manual

Register Name Type Write Read Read Response Description
4243 KEY FUNC3 PRESS UINT16 FBT3,,<value>; Function key 3 press (0 short, 1
long)
4251 DISPLAY BRIGHTNESS UINT16 BRT<value>; BRT?; <value> Display brightness
4301 RESET UNIT UINT16 RES; Reset unit
5001 DOUT1 UINT16 FOP<value>; FOP?; <value> Digital output 1 state
5002 DOUT2 UINT16 FOP,<value>; FOP?; ,<value> Digital output 2 state
5003 DOUT3 UINT16 FOP,,<value>; FOP?; ,,<value> Digital output 3 state
5004 DOUT4 UINT16 FOP,,,<value>; FOP?; ,,,<value> Digital output 4 state
5005 DOUT5 UINT16 FOP,,,,<value>; FOP?; ,,,,<value> Digital output 5 state
5006 DOUT6 UINT16 FOP,,,,,<value>; FOP?; ,,,,,<value> Digital output 6 state
5007 DOUT7 UINT16 FOP,,,,,,<value>; FOP?; ,,,,,,<value> Digital output 7 state
5008 DOUT8 UINT16 FOP,,,,,,,<value>; FOP?; ,,,,,,,<value> Digital output 8 state
5011 DOUT1 UINT16 POR<value>; POR?; <value> Digital output 1 state
5012 DOUT2 UINT16 POR,<value>; POR?; ,<value> Digital output 2 state
5013 DOUT3 UINT16 POR,,<value>; POR?; ,,<value> Digital output 3 state
5014 DOUT4 UINT16 POR,,,<value>; POR?; ,,,<value> Digital output 4 state
5015 DOUT5 UINT16 POR,,,,<value>; POR?; ,,,,<value> Digital output 5 state
5016 DOUT6 UINT16 POR,,,,,<value>; POR?; ,,,,,<value> Digital output 6 state
5017 DOUT7 UINT16 POR,,,,,,<value>; POR?; ,,,,,,<value> Digital output 7 state
5018 DOUT8 UINT16 POR,,,,,,,<value>; POR?; ,,,,,,,<value> Digital output 8 state
5101 SP1 TYPE UINT16 LIV1,<value>; LIV?1; 1,<value> Setpoint 1 type
5102 SP1 SOURCE UINT16 LIV1,,<value>; LIV?1; 1,,<value> Setpoint 1 source
5104 SP1 TARGET SINT32 LIV1,,,,<value>; LIV?1; 1,,,,<value> Setpoint 1 target
5106 SP1 INFLIGHT SINT32 LIV1,,,,,<value>; LIV?1; 1,,,,,<value> Setpoint 1 inflight
5108 SP1 HYSTERESIS SINT32 LIV1,,,,,,<value>; LIV?1; 1,,,,,,<value> Setpoint 1 hysteresis
5110 SP1 LOGIC UINT16 LIV1,,,,,,,<value>; LIV?1; 1,,,,,,,<value> Setpoint 1 logic inversion
5111 SP1 LOCK UINT16 LIV1,,,,,,,,<value>; LIV?1; 1,,,,,,,,<value> Setpoint 1 lock
5112 SP1 ALARM UINT16 LIV1,,,,,,,,,<value>; LIV?1; 1,,,,,,,,,<value> Setpoint 1 alarm
5113 SP1 TIMING UINT16 LIV1,,,,,,,,,,<value>; LIV?1; 1,,,,,,,,,,<value> Setpoint 1 timing
5114 SP1 RESET UINT16 LIV1,,,,,,,,,,,<value>; LIV?1; 1,,,,,,,,,,,<value> Setpoint 1 reset
5121 SP2 TYPE UINT16 LIV2,<value>; LIV?2; 2,<value> Setpoint 2 type
5122 SP2 SOURCE UINT16 LIV2,,<value>; LIV?2; 2,,<value> Setpoint 2 source
5124 SP2 TARGET SINT32 LIV2,,,,<value>; LIV?2; 2,,,,<value> Setpoint 2 target
5126 SP2 INFLIGHT SINT32 LIV2,,,,,<value>; LIV?2; 2,,,,,<value> Setpoint 2 inflight
5128 SP2 HYSTERESIS SINT32 LIV2,,,,,,<value>; LIV?2; 2,,,,,,<value> Setpoint 2 hysteresis
5130 SP2 LOGIC UINT16 LIV2,,,,,,,<value>; LIV?2; 2,,,,,,,<value> Setpoint 2 logic inversion
5131 SP2 LOCK UINT16 LIV2,,,,,,,,<value>; LIV?2; 2,,,,,,,,<value> Setpoint 2 lock
5132 SP2 ALARM UINT16 LIV2,,,,,,,,,<value>; LIV?2; 2,,,,,,,,,<value> Setpoint 2 alarm
5133 SP2 TIMING UINT16 LIV2,,,,,,,,,,<value>; LIV?2; 2,,,,,,,,,,<value> Setpoint 2 timing
5134 SP2 RESET UINT16 LIV2,,,,,,,,,,,<value>; LIV?2; 2,,,,,,,,,,,<value> Setpoint 2 reset
5141 SP3 TYPE UINT16 LIV3,<value>; LIV?3; 3,<value> Setpoint 3 type
5142 SP3 SOURCE UINT16 LIV3,,<value>; LIV?3; 3,,<value> Setpoint 3 source
5144 SP3 TARGET SINT32 LIV3,,,,<value>; LIV?3; 3,,,,<value> Setpoint 3 target
5146 SP3 INFLIGHT SINT32 LIV3,,,,,<value>; LIV?3; 3,,,,,<value> Setpoint 3 inflight
5148 SP3 HYSTERESIS SINT32 LIV3,,,,,,<value>; LIV?3; 3,,,,,,<value> Setpoint 3 hysteresis
5150 SP3 LOGIC UINT16 LIV3,,,,,,,<value>; LIV?3; 3,,,,,,,<value> Setpoint 3 logic inversion
5151 SP3 LOCK UINT16 LIV3,,,,,,,,<value>; LIV?3; 3,,,,,,,,<value> Setpoint 3 lock
5152 SP3 ALARM UINT16 LIV3,,,,,,,,,<value>; LIV?3; 3,,,,,,,,,<value> Setpoint 3 alarm
5153 SP3 TIMING UINT16 LIV3,,,,,,,,,,<value>; LIV?3; 3,,,,,,,,,,<value> Setpoint 3 timing
5154 SP3 RESET UINT16 LIV3,,,,,,,,,,,<value>; LIV?3; 3,,,,,,,,,,,<value> Setpoint 3 reset
5161 SP4 TYPE UINT16 LIV4,<value>; LIV?4; 4,<value> Setpoint 4 type
5162 SP4 SOURCE UINT16 LIV4,,<value>; LIV?4; 4,,<value> Setpoint 4 source
5164 SP4 TARGET SINT32 LIV4,,,,<value>; LIV?4; 4,,,,<value> Setpoint 4 target
5166 SP4 INFLIGHT SINT32 LIV4,,,,,<value>; LIV?4; 4,,,,,<value> Setpoint 4 inflight
5168 SP4 HYSTERESIS SINT32 LIV4,,,,,,<value>; LIV?4; 4,,,,,,<value> Setpoint 4 hysteresis
5170 SP4 LOGIC UINT16 LIV4,,,,,,,<value>; LIV?4; 4,,,,,,,<value> Setpoint 4 logic inversion
5171 SP4 LOCK UINT16 LIV4,,,,,,,,<value>; LIV?4; 4,,,,,,,,<value> Setpoint 4 lock
5172 SP4 ALARM UINT16 LIV4,,,,,,,,,<value>; LIV?4; 4,,,,,,,,,<value> Setpoint 4 alarm
5173 SP4 TIMING UINT16 LIV4,,,,,,,,,,<value>; LIV?4; 4,,,,,,,,,,<value> Setpoint 4 timing
5174 SP4 RESET UINT16 LIV4,,,,,,,,,,,<value>; LIV?4; 4,,,,,,,,,,,<value> Setpoint 4 reset
5181 SP5 TYPE UINT16 LIV5,<value>; LIV?5; 5,<value> Setpoint 5 type
5182 SP5 SOURCE UINT16 LIV5,,<value>; LIV?5; 5,,<value> Setpoint 5 source
5184 SP5 TARGET SINT32 LIV5,,,,<value>; LIV?5; 5,,,,<value> Setpoint 5 target
5186 SP5 INFLIGHT SINT32 LIV5,,,,,<value>; LIV?5; 5,,,,,<value> Setpoint 5 inflight
5188 SP5 HYSTERESIS SINT32 LIV5,,,,,,<value>; LIV?5; 5,,,,,,<value> Setpoint 5 hysteresis
5190 SP5 LOGIC UINT16 LIV5,,,,,,,<value>; LIV?5; 5,,,,,,,<value> Setpoint 5 logic inversion
99 C500-600-2.0.3
