Page #151 background image
Command Answer Description
S01; Select unit 1
MSM?; 002000,12 CRLF Query displayed weight. Status is gross and motion.
MSM?3; 000100,0 CRLF Query net weight
21.3.36 MSV?: Current Weight
Query weight readings.
General
No. of parameters 2
Save changes -
Increment Trade Counter -
Parameter Details
Parameter Description Range Default
1 Type of reading 1 = Displayed weight
2 = Gross weight
3 = Net weight
4 = Number of items in total weight
5 = Total 1
6 = Total 2
7 = Peak weight
8 = Live weight
-
2 Number of consecutive readings 0 .. 60000
(0 means continuous output)
1
Example
Command Answer Description
S01; Select unit 1
COF3; 0 CRLF Set output format 3
MSV?; 00200.0 CRLF Query displayed weight
MSV?2; 00400.0 CRLF Query gross weight
MSV?2,5; 00400.0 CRLF
00400.1 CRLF
00400.2 CRLF
00400.3 CRLF
00400.4 CRLF
CRLF
Query the next 5 consecutive gross weight readings
MSV?,0; 00400.0 CRLF
00400.1 CRLF
00400.2 CRLF
....
Enable continuous output
STP; Stop continuous output
Note
CRLF is sent after each reading for the ASCII formats but not for the binary for-
mats. With the binary formats a single CRLF is sent at the end of the response
regardless of the number of readings requested. To stop continuous output send a
STP; command. During continuous output the indicator will not respond to other
commands.
146 C500-600-2.0.3
