88
Store Operation
6. Specify the store name.
6-1. Use the
keys to select [Store name] and press the MENU/
ENTER key. The store name screen appears.
6-2. Use the
keys to select the  rst two digits, and use the
keys to set the value.
6-3. Use the keys to select the  nal two digits, and use the
keys to set the value. Then press the MENU/ENTER key.
7. Set the measurement channel.
7-1. Use the
keys to select [Measurement channel] and press
the MENU/ENTER key. The measurement channel setting screen
appears.
7-2. Use the
keys to select the measurement channel (Z, XYZ)
and press the MENU/ENTER key.
8. Set the total measurement time.
8-1. Use the
keys to select [Total Measurement Time] and press
the MENU/ENTER key. The total measurement time screen
appears.
8-2. Use the
keys to select the total measurement time (500s,
10s, 1min, 5min, 10min, 15min, 30min, 1h, 8h, 24h, User setting)
and press the MENU/ENTER key.
8-3. When “User setting” is selected, [User setting] is displayed on the
store screen. Select [User setting] and press the MENU/ENTER
key.
8-4. The total measurement time setting screen appears. Set arbitrary
total measurement time . The shortest time value that can be set
with “User setting” is 1 second and the longest is 1,000 hours.
9. Set the L
v
store interval.
9-1. Use the
keys to select [Lv Store Interval] and press the
MENU/ENTER key. The L
v
store interval screen appears.
9-2. Use the
keys to select the L
v
store interval (OFF, 100ms,
1s) and press the MENU/ENTER key.
If the L
v
store interval set to OFF, L
v
is not stored.
