Rion VM-55 - Connection to a Frequency Analyzer

30
Preparations
Connection to a frequency analyzer
Connect the OUTPUT connector on the right side of the VM-55 with an input
connector of frequency analyzer, using the optional BNC - Pin output cord
CC-24 as shown below. The performance of other cables is not guaranteed.
OUTPUT
X
Y
Z
OUTPUT
connectors
BNC connector
Open
the side cover
BNC - Pin output cord CC-24
To input connector
on frequency analyzer
